Description

Dual channel monitor for the continuous measurement of pH and Redox (ORP) potential in potable water and effluents.



Complete system mounted on PVC panel including:

• Dual channel transmitter AMI pH/mV:pH/mV
• Flow cell M-Flow 10-3PG with temperature sensor (NT5K).
• Factory tested, ready for installation and operation.



For use with combined sensors with reference (order seperately):

• Swansensor pH Standard and ORP Standard
• Swansensor pH AY and ORP AY



Optional accesory:

• Spray nozzle for sensor cleaning
• Swansensor deltaT flow meter
• Swan AMI Relaybox

Specifications

pH Measurement
Measuring range with Swansensor ST/AY	pH 1 to 13
Measuring range with Swansensor SI	pH 1 to 12
Resolution	0.01 pH
Reference temperature	25° C
Automatic temperature compensation according to Nernst.
ORP (Redox) measurement
Measuring range with Swansensor ST/AY	-400 to 1'200 mV
Measuring range with Swansensor SI	-500 to 1'500 mV
Resolution	1 mV
Temperature measurement
Measuring range	-30 to 130°C
Resolution	0.1° C
Power Supply
Voltage	100-240 VAC (+- 10%), 50/60 Hz (+- 5%) or 24 VDC (+- 10%)
Sample conditions
Flow rate	4 to 15 l/h
Temperature	up to 50° C
Inlet pressure	up to 1 bar
Outlet pressure	pressure free
Dimensions
Panel	280 x 850 x 150 mm

For further information see datasheet.
